We are the renowned manufacturer, supplier and trader of Fully Automatic VFFS Machines. Efficiency and reliability are highly appreciated by our clients. The materials used to manufacture these products are sourced from trustworthy vendors. Before the final delivery of these machines, our team of expert professionals checks its functionality and finishing. Fully Automatic VFFS Machines are known for its durability, excellent performance and corrosion resistance are some of its features. Simple operation and low maintenance are highly appreciated by our customers.
Model AP-250L-Single Track is having the capacity to pack 100 ML and above of product. This can go up to a speed of 50 SPM and is installed with servo & stepper motor film draw mechanism. It is available in 3 side, 4 side and Center sealing and can be installed easily. Our range of this model comes in single track or twin tracks and is used to pack liquid and paste products. This model of VFFS machines is known for its durability, efficiency and functionality due to which we have been able to gain huge market credibility. Various web controller options available in this model are electronic web edge control and pneumo hydraulic web edge controller.
|Machine speed||Up to 150 SPM depending on the product & sachet/pouch dimension.|
|Packing range||Suitable to pack up to 100 ml and above depending upon product to be tacked|
|No. of tracks||Single or twin tracks|
|Max. roll width||250 mm|
|Max. roll dia||200 mm|
|Max length of pouch||Up to 130mm|
|Film draw mechanism||Options |
|Web controller||Options |
Electronic web edge control.
Pneumo hydraulic web edge controller
|Compressed air||2CFM @ 6 kg/cm sq.|
|Electrical power required||Up to 6KW|
|Main Body Frame||Option |
MS with Powder coating.
MS with SS cladding
|Type of Sealing||4 Side Sealing |
3 Side Sealing
|Machine dimension||2000 mm X 1065 mm X 1075 mm |
(Height mm X Width mm X Length mm)
|Net weight||700 kg|
