With an aim to fulfil varied needs of different industrial applications, we are affianced in providing technologically advanced Auger Filler Machine. Offered machine is manufactured using supreme grade components and by implementing ultra-modern technology in line with defined global market standards. Designed for sealing non-free flow powder like mehandi, dye, soup powder, hair dye, spices, etc., this machine is can operate on a speed of 70 SPM depending on the width of pouch. Further, this Auger Filler Machine have excellent functioning and requires less maintenance, due to this attribute offered machine is widely demanded by our customers.
High operational fluency
Longer service life
Model AP-1000 P AUGUR FILLER -Up to 10 Tracks is used for sealing of Non- free flow powder like SPICES,MEHNDI,HAIR DYE,SOUP POWDERS,etc. It can operate on a speed of 70 SPM and can drive up to 10 tracks depending on the width of the pouch being used.
It is provided with individual filling servo (to operate individual track through servo motor), electronic web edge controller and is available in various coatings such as MS with powder coating and MS with SS cladding. We utilize latest technologies to manufacture these machines so that they offer excellent performance for a longer period of time. Owing to their robust construction and superior quality raw material, they require less maintenance, which cuts down its wear, & tear costs tremendously.
|Machine speed ||Up to 70 SPM depending on the product & sachet/pouch dimension |
|Packing range ||Suitable to pack up to 500 gram and depending upon product to be packed |
|No. of tracks ||Up to 10 tracks depending on sachet/pouch width |
|Max. roll width ||1000 mm |
|Max. roll dia ||500 mm |
|Max length of pouch ||Up to 220mm |
|Film draw mechanism |
a) Servo based
b) Electromagnetic clutch and break
Augur Filling System - Individual Servo For Individual Tracks.
|Web controller ||a) Pneumo hydraulic web edge |
b) Electronic web edge controller
|Compressed air ||4 CFM @ 6 kg/cm sq. |
|Electrical power required ||Up to 8 KW |
|Main Body Frame ||Option:- |
- MS with Powder coating.
- MS with SS cladding
|Type of Sealing ||4 Side Sealing |
|Machine dimension ||3190 mm x 3285 mm x 1950 |
(Height mm x Width mm x Length mm)
|Net weight ||3300 kg |
